Trung tâm báo cháy Smarthome SM-200C Fire Alarm
Our fire alarm features a wireless smog detector, which fits the UL217 standard and covers 20 square meters. The detector will monitor the surroundings every 45 seconds. Once the smog is detected, our fire alarm will activate siren and print the alarm message immediately. Special digital processing chip is used to manage 999 kinds of wireless detectors at the same time. Together with high sensitivity and large coverage, our fire alarm provides comprehensive solution for enterprise, family and offices against fire.
Technical specifications of fire alarm
| Power | AC 220V±15% 50Hz
DC:12V-13.8V | Working Current | Standby current: ≤130mA
Alarm Current:≤800mA |
| Working Environment | -20 ℃ ~ 60 ℃ | Alarm Loudness: | ≥100dB within 1m |
| Wireless Frequency | 229Mhz | Wireless Receiving Distance | 3-10km |
| Sensitivity of Receiver | ≤0.2uA (12uB) | Dial Mode | DTMF (Double-tone Multi Frequency) |
| Resistance | ≤300 tile | Size(L*W*H) | 370*330*150 (mm) |
Standard packaging of fire alarm
| Standard Packaging | Quantities |
| Main panel | 1pc |
| Rechargeable storage battery | 1pc |
| White cardboard box | 1pc |
Our fire alarm is able to handle 999 zones independently. Each zone can be defined as common zone or emergency zone. A large LCD display enables our fire alarm to query the latest 100 records, while a voice guide is provided. Our system also adopts a mini printer. The alarm record can be printed immediately. An optional build-in or external battery is used to provide backup power supply. Moreover, if the power is low, our fire alarm will alert this status by voice or printing.
Our fire alarm uses register code between wireless sensors and the main unit. It is easy for extension and maintenance. Moreover, no false code occurs at this configuration. Our audio signal output can be connected with 8 or 15 W passive horn or loud speaker. They will replace the build-in siren once activated.
